Sealed & Packaging Leak Tester
G4/GV
Method: Vacuum Decay
Sealed & packaging leak tester — non-destructive package seal integrity testing by vacuum decay (ASTM F2338)
G4/GV evaluates package seal integrity with the vacuum decay method, compliant with ASTM F2338-09 (2013) — Standard Test Method for Nondestructive Detection of Leaks in Packages by Vacuum Decay Method. The test runs in three steps: (A) the equipment electronically controls the test vacuum, (B) it checks for gross leaks by measuring the volume being analyzed, and (C) it detects micro-leaks by analyzing the pressure rise inside the chamber. Because the test is non-destructive, approved samples can go back to production instead of being discarded.
Key benefits
✓Non-destructive — approved samples return to production
✓Compliant with ASTM F2338 vacuum decay method
✓Detects both gross leaks and micro-leaks
✓Flexible chamber for flexible, semi-rigid and rigid packages
✓Supports products with air or modified atmosphere (MAP: CO2, N2, O2)
Technical Specifications
MethodVacuum Decay
StandardASTM F2338-09 (2013)
Test typeNon-destructive
DetectionGross leak + micro-leak
ChamberFlexible chamber
PackagesFlexible / semi-rigid / rigid, air or MAP
Applications
Food — bottles/jars, stand-up pouches, retort pouches, sachets
Pharmaceutical — blister packs, glass & plastic bottles/jars, sterile packages, sachets
Packaging converters — glass & plastic bottles/jars, pouches, sachets
